inside the video image. Use the arrows to proceed.
•Time
Time allows you to choose the position of the current time insertion
inside the video image. Use the arrows to proceed.
• Cam
Cam allows you to choose the position of the magazine number
insertion inside the video image. Use the arrows to proceed.
• Frame
Frame/Frame On-Off allows you to choose if you want (On) or not
(Off) a frame to be inserted in the video image.
Frame/Frame Top Left allows you to choose the position of the top
left position of the frame. Use the arrows to proceed.
Frame/Frame Botton Right allows you to choose the position of the
bottom right position of the frame. Use the arrows to proceed.
Frame/Edge allows you to choose between an Edge around the fra-
me, or No Egde.
• Phase adjust
Phase adjust is designed to move the flicker area outside the video
image. This function is available only when the CD56 and the
AATON 35-III are running at the same speed (both at 25 fps, for
example). Use the up and down arrows for a first quick phase
adjustment. And then, use the left and right arrows for a fine adjust-
ment. To proceed, run the camera and watch the video monitor.
• Options
Options allows you to access to a submenu only dedicated to the
AatonCode insertion.
Options/Screen allows you to choose to insert (On) or not (Off)
AatonCode information, which consists of Time, Date, and Equip-
ment number ID.
Options/Screen Y/C allows you to choose to insert (On) or not
(Off) the Y/C video exit informations.
Options/Font allows you to choose the font you need for the charac-
ters to be inserted. Choose 0 for edged characters, 1 for standard
characters, and 2 for bold characters.
• Technical
42
