Technical allows you to access to a submenu only dedicated to the
Vitc lines insertion. These lines are automatically inserted in the
video image.
Technical/XTAL Adjust is a parameter adjusted in factory. Keep in
mind that you should never modify it.
Technical/VITC Position allows you to choose the position of the
Vitc lines. Choose between line 16 and line 24.
Technical/VITC Parity allows you to select the parity of the Vitc
lines between Odd and Even. Make sure that your post-production
tools run properly with the selected value.
• About the Vitc lines
In order to have meaningful information encoded in the Vitc lines,
camera and video need to run at the same speed. If the video is set
to run at 25 fps, then the AATON 35-III should run at 25 fps.
And when the video is set to 24 fps, the AATON 35-III should run
at 23.98 fps (this slight variation between these two speeds comes
from some electronical imperious needs).
If the third Vitc line cannot be generated by the CD56, then a (*)
appears on the screen. This might occur because of two different
situations: whether the speeds of the AATON 35-III and the CD56
are different, or AatonCode has not be initialized inside the
AATON 35-III.
43
THE CAMERA BODY
