22 OI/266/FF/ADD-EN Rev. B | 2600T Series Pressure transmitters
266 Models - FOUNDATION Fieldbus
Idx Parameter Data Type Size Storage Description / Range / Selections / Note
22 PILD_TRAIN_OUTPUT R S U8 1 D
This parameter gives information on the
status of the training phase
Bit 0: PILD Train Not Done Training not yet executed
Bit 1: PILD Train OK Training correct
Bit 2:
PILD Train Frequency
Tuning
The training phase is checking the signal frequency
for its execution
Bit 3:
PILD Train Power
Instable
Signal power has passed the max. allowed deviation
This process condition is considered instable for a
good training
Bit 4:
PILD Train Pressure
Instable
Pressure has passed the max.allowed deviation.
This process condition is considered instable for a
good training
Bit 5: PILD Train Low Noise
The Noise of the process is too low for allowing a
good training
Bit 6: not used
Bit 7: not used
23 PILD_SENSITIVITY RW S U8 1 S Algorithm sensibility
1: LOWEST
2: VERY LOW
3: LOW
4: MEDIUM (Default)
5: HIGH
6: VERY HIGH
7: HIGHEST
24
PILD_BAND_
AUTOTUNING
RW S U8 1 S PILD auto tuning enable/disable
0 No Doesn’t perform auto tune (default value)
1 Yes Performs Auto Tune
25 PILD_BAND_LO RW S U8 1 S
Writable only if PILD_BAND_AUTOTUNING is set to 0
26 PILD_BAND_HI RW S U8 1 S
27 PWR_ON_CNT R S U16 2 D
Power On Counter. Number of the device Power on
28 TOT_WORK_TIME R S DS-13 6 D
Total Working hours. Total amount of time the transmitter has been kept
switched on
29 PAR_WORK_TIME RW S DS-13 6 D
Partial Working hours. Partial amount of time the transmitter has been switched on. The user can clear this counter
30 MAX_PdP_VALUE R S FLT 4 N
Max Historical Sensor value
Resettable from RESET_MIN_MAX_VALUE
31 MIN_PdP_VALUE R S FLT 4 N
Min Historical Sensor value
32 MAX_SENS_TEMP_VAL R S FLT 4 N
Max Historical temp. value
33 MIN_SENS_TEMP_VAL R S FLT 4 N
Min Historical temp. value
34 MAX_STATIC_PRESS_VAL R S FLT 4 S
Max Historical Static Press value
35 MIN_STATIC_PRESS_VAL R S FLT 4 S
Min Historical Static Press value
36 RESET_MIN_MAX_VALUE W S U8 1 N Reset the selected User Min Max values
0 None
1 Reset PdP Values
2
Reset Sensor Tempera-
ture Values
3
Reset Static Pressure
Values
