2600T Series Pressure transmitters | OI/266/FF/ADD-EN Rev. B 87
Initialization
The 266 PdP implements up to three Analog Input Blocks, 2 of Enhanced category and 1 Standard. Each AI produce in output one
variable (AIx_OUT) suitable to be linked to other downstream function blocks. The three AIs receive in input one of the variables
produced by the Pressure Transducer Block depending by their own AIx_CHANNEL setting.
The default AIx_CHANNEL setting is:
– The Analog Input 1 receives in input the PRTB_PRIMARY_VALUE (Process Pressure) through the AI1_CHANNEL = 1.
– The Analog Input 2 receives in input the PRTB_TERTIARY_VALUE (Static Pressure) through the AI2_CHANNEL = 3.
– The Analog Input 3 receives in input the PRTB_SECONDARY_VALUE (Sensor Temperature) through the AI3_CHANNEL = 2.
Hovewer all the 3 AIx_CHANNEL can be switched to receive in input up to different 4 PRTB variables:
AI CHANNEL Variables PRTB_Variable
0
Uninitialized None
1
Pressure Process Value PRIMARY_VALUE
2
Sensor Temperature SECONDARY_VALUE
3
Static Pressure TERTIARY_VALUE
4
Scaled Process Value QUATERNARY_VALUE
Factory settings
Transmitters are calibrated at the factory to the customer’s specified measuring range. The calibrated range and tag number are
provided on the name plate. If this data has not been specified, the transmitter will be delivered with the following configuration:
Process Info Parameter Factory setting
Node Address
248
TAG
PD_TAG “PI000”
Calibration Lower Range Value 0%
PRTB_PRIMARY_VALUE_RANGE_0% 0.0
Calibration Upper Range Value 100%
PRTB_PRIMARY_VALUE_RANGE_100% PTRB_SENSOR_RANGE_100%
Calibration Unit
PRTB_PRIMARY_VALUE_RANGE_UNIT Kpa
Transfer function
PTRB_QUATERNARY_VALUE_LIN_TYPE Linear
Display Mode
HMI_MODE One Line
Display Variable
HMI_LINE1 HMI_VARIABLE_1 = PRTB_PRIMARY_VALUE
Analog Input 1 setting
Channel AI1_CHANNEL 1 = PV
Damping AI1_PV_FTIME 0 second
Calibation Lower Range Value 0% AI1_XD_SCALE 0% 0.0
Calibation Upper Range Value 100% AI1_XD_SCALE 100% PTRB_SENSOR_RANGE_100%
Calibration Unit AI1_XD_SCALE_UNIT Kpa
Output scale 0% AI1_OUT_SCALE 0% 0.0
Output scale 100% AI1_OUT_SCALE 100% PTRB_SENSOR_RANGE_100%
Output Scale Unit AI1_OUT_SCALE_UNIT Kpa
Linearization AI1_L_TYPE Direct
Critical Limit Low AI1_LO_LO_LIM AI1_OUT_SCALE 0% - 10% of the SPAN
Advisory Limit Low AI1_LO_LIM
Advisory Limit High AI1_HI_LIM AI1_OUT_SCALE 100% + 10% of the SPAN
Critical Limit High AI1_HI_HI_LIM
Alarm Hysteresis AI1_ALARM_HYS 0.5% of the SPAN
Analog Input 2 setting (applicable only for differential pressure sensor types)
Channel AI2_CHANNEL 3 = Static Pressure
Damping AI2_PV_FTIME 0 second
Calibation Lower Range Value 0% AI2_XD_SCALE 0% 0.0
Calibation Upper Range Value 100% AI2_XD_SCALE 100% PTRB_TERTIARY_VALUE_RANGE_100%
Calibration Unit AI2_XD_SCALE_UNIT MPa
Output scale 0% AI2_OUT_SCALE 0% 0.0
