88 OI/266/FF/ADD-EN Rev. B | 2600T Series Pressure transmitters
266 Models - FOUNDATION Fieldbus
Output scale 100% AI2_OUT_SCALE 100% PTRB_TERTIARY_VALUE_RANGE_100%
Output Scale Unit AI2_OUT_SCALE_UNIT MPa
Linearization AI2_L_TYPE Direct
Critical Limit Low AI2_LO_LO_LIM AI2_OUT_SCALE 0% - 10% of the SPAN
Advisory Limit Low AI2_LO_LIM
Advisory Limit High AI2_HI_LIM AI2_OUT_SCALE 100% + 10% of the SPAN
Critical Limit High AI2_HI_HI_LIM
Alarm Hysteresis AI2_ALARM_HYS 0.5% of the SPAN
Analog Input 3 setting
Channel AI2_CHANNEL 3 = Static Pressure
Channel AI3_CHANNEL 2 = Sensor temperature
Damping AI3_PV_FTIME 0 second
Calibation Lower Range Value 0% AI3_XD_SCALE 0% PTRB_ SECONDARY_VALUE_RANGE_0%
Calibation Upper Range Value 100% AI3_XD_SCALE 100% PTRB_ SECONDARY_VALUE_RANGE_100%
Calibration Unit AI3_XD_SCALE_UNIT °C
Output scale 0% AI3_OUT_SCALE 0% PTRB_ SECONDARY_VALUE_RANGE_0%
Output scale 100% AI3_OUT_SCALE 100% PTRB_ SECONDARY_VALUE_RANGE_100%
Output Scale Unit AI3_OUT_SCALE_UNIT °C
Linearization AI3_L_TYPE Direct
Critical Limit Low AI3_LO_LO_LIM AI3_OUT_SCALE 0% - 10% of the SPAN
Advisory Limit Low AI3_LO_LIM
Advisory Limit High AI3_HI_LIM AI3_OUT_SCALE 100% + 10% of the SPAN
Critical Limit High AI3_HI_HI_LIM
Alarm Hysteresis AI3_ALARM_HYS 0.5% of the SPAN
Important
All the above configurable parameters can be afterward modified via DD based software tools
