26 OI/266/FF/ADD-EN Rev. B | 2600T Series Pressure transmitters
266 Models - FOUNDATION Fieldbus
Idx Parameter Data Type Size Storage Description / Range / Selections / Note
17 HMI_LIN_TYPE RW S U8 1 S
4: cylindrical lying container Active only if one of the 4 HMI_Variable_x is set to HMI_Variable. In this case
the PRTB_PRIMARY_VALUE is calculated with the selected HMI_LIN_TYPE
and the result ready to be scaled with the HMI_VARIABLE_RANGE.
5: spherical container
6: Bidirectional Flow
18 HMI_VARIABLE_RANGE RW R DS-68 11 S The High and Low HMI Scale limits
with the engineering units code
Scaling applied at the PRTB_PRIMARY_VALUE for displaying purpose only and has
not effect on the PRTB_PRIMARY_VALUE in input at the AI blocks.
19 HMI_VARIABLE_CUSTOM_UNIT RW S V_STR 8 S
Textual custom unit
20 HMI_LINE_1 RW S U8 1 S
1: HMI_Variable 1 (default)
2: HMI_Variable 2
3: HMI_Variable 3
4: HMI_Variable 4
21 HMI_LINE_2 RW S U8 1 S Same as HMI_LINE_1
22 HMI_BARGRAPH RW S U8 1 S Same as HMI_LINE_1
23 HMI_SEQUENCE RW S U8 1 S
0 Sequence/Autoscrolling OFF
1 Sequence/Autoscrolling ON
24 HMI_VARIABLE_1 RW S U8 1 S
In order to recognize the displayed variable among all those in this list, it appears a three character string in the left side of the
value when two lines mode is selected and below the value when One Line Mode is selected. The strings for any variables are:
0: P-dP (default) ‘PV’
6:
OUT AI_1 ‘AI1’
7:
OUT % AI_1 ‘%1’
8:
OUT AI_2 ‘AI2’
9:
OUT % AI_2 ‘%2’
10:
OUT AI_3 ‘AI3’
11:
OUT % AI_3 ‘%3’
1:
Sensor Temp ‘ST’
2:
Static Pressure ‘SP’
19:
HMI Variable ‘HMI’
4:
PV Trim Value ‘TPV’
5
Static Pressure Trim Value ‘TSP’
3
Scaled PV ‘LIN’
16
OUT1 SC ‘SC1’
17
OUT2 SC ‘SC2’
12
OUT PID ‘PID’
18
OUT AR ‘AR’
14
OUT IS ‘IS’
15
OUT IT ‘IT’
13
OUT CS ‘CS’
25 HMI_VARIABLE_2 RW S U8 1 S Same as HMI_VARIABLE_1
26 HMI_VARIABLE_3 RW S U8 1 S Same as HMI_VARIABLE_1
27 HMI_VARIABLE_4 RW S U8 1 S Same as HMI_VARIABLE_1
