56 OI/266/FF/ADD-EN Rev. B | 2600T Series Pressure transmitters
266 Models - FOUNDATION Fieldbus
Idx Parameter Data Type Size Storage Description / Range / Selections / Note
19 SEL_TYPE RW S U8 1 S
This parameter specifies the type of selector action
1 First Good
2 Minimum
3 Maximum
4 Middle
5 Average
20 MIN_GOOD RW S U8 1 S 0 - 4 If the number of inputs which are good is less than the value of MIN_GOOD then set the out status to bad.
21 SELECTED RW R DS-66 2 D 0 - 4 An integer indicating which input has been selected
22 OP_SELECTED RW R DS-66 2 N 0 - 4 An operator settable parameter to force a given input to be used
23
UPDATE_EVT R R DS-73 14 D This alert is generated by any change to the static data
24 BLOCK_ALM RW R DS-72 13 D
The block alarm is used for all configuration, hardware, connection failure or system problems in the block. The cause of the
alert is entered in the subcode field. The first alert to become active will set the Active Status in the status parameter. As soon
as the Unreported status is cleared by the alert reporting task, another block alert may be reported without clearing the Active
Status, if the subcode has changed
