2600T Series Pressure transmitters | OI/266/FF/ADD-EN Rev. B 71
Idx Parameter Data Type Size Storage Description / Range / Selections / Note 28 INTEG_TYPE RW S U8 1 S
Defines the type of counting (up or down) and the type of resetting (demand or periodic) 0 Not Initialized 1 UP AUTO 2 UP DEM 3 DN AUTO 4 DN DEM 5 PERIODIC 6 DEMAND 7 PER & DEM
29 INTEG_OPTS RW S B_STR 2 S
A bit string to configure the type of input (rate or accum.) used in each input, the flow direction to be considered in the totalization, the status to be considered in TOTAL and if the totalization residue shall be used in the next batch (only when INTEG_TYPE = UP_AUTO or DN_AUTO). Bit 0 Input 1 Accumulate Bit 1 Input 2 Accumulate Bit 2 Flow Forward Bit 3 Flow Reverse Bit 4 Use Uncertain Bit 5 Use Bad Bit 6 Carry Bit 7 Add zero if Bad Bit 8 Confirm Reset Bit 9 Generate Reset Event
30 CLOCK_ERR RW S FLT 4 S 0 or > 0 Establishes the period for periodic reset, in seconds 31 PRE_TRIP RW S FLT 4 S 0 or > 0
Value used for the OUT_PTRIP setting. It adjusts the amount of mass, volume or energy that should set OUT_PTRIP when the integration reaches (TOTAL_SP - PRE_TRIP) when counting UP or PRE_
TRIP when counting DOWN. Expressed in OUT_RANGE Unit
32 N_RESET R S FLT 4 N
The number of resets is counted in the register N_RESET. This counter can not be written or reset. It provides verification that the
TOTAL has not been reset since N_RESET was last checked. The counter should roll over from 999999 to 0.
33 PCT_INCL R S FLT 4 D This value is the % of the absolute net increment with good status respect of the absolute net increment regardless of the status. 34 GOOD_LIM RW S FLT 4 S If PCT_INCL ≥ GOOD_LIM and the mode is AUTO the status of the OUT is GOOD_NC otherwise check the other limit. Expressed in % 35 UNCERT_LIM RW S FLT 4 S If PCT_INCL ≥ UNCERT_LIM and the mode is AUTO the status of the OUT is UNCERTAIN otherwise is BAD. Expressed in % 36 OP_CMD_INT RW S U8 1 D
0 OFF
Operator reset command. Resets the totalizer
1 ON
37 OUTAGE_LIM RW S FLT 4 S 0 or > 0 The max, tolerated duration for power failure. This value is used by the host expressed in seconds 38 RESET_CONFIRM RW R DS-66 2 N
0 OFF
If the Confirm Reset in the INTEG_OPTS is set, any further reset will be prevented until a logic 1 is not
received in input to the RESET_CONFIRM. If not connected it acts like a momentary dynamic parame- ter. This ensures that a host has recorded the snapshot values before the next reset can occur.
1 CONFIRM
39 UPDATE_EVT R R DS-73 14 D This alert is generated by any change to the static data 40 BLOCK_ALM RW R DS-72 13 D
The block alarm is used for all configuration, hardware, connection failure or system problems in the block. The cause of the alert is entered in the subcode field. The first alert to become active will set the Active Status in the status parameter. When the Unreported status is cleared by the alert reporting task, another block alert may be reported without clearing the Active Status, if the subcode has changed
