ABB 266HSH Operating Instructions

12 OI/266/LowP-EN Rev.A | 2600T Series Pressure transmitters
5 Mounting
36 (1.42) width across flats
18 (0.71)
113 (4.45)
18 (0.71)
145 (5.71)
91 (3.58)
18 (0.71) 16 (0.63)
108 (4.25)
72 (2.83)
65 (2.56)
40 (1.58)
72 (2.83)
18 (0.71)
113 (4.45)
18 (0.71)
145 (5.71)
18 (0.71) 16 (0.63)
108 (4.25)
52 (2.05)
27 (1.06) width
across flats
Figure 7: Model 266HSH with 1/2-14 NPT male process connection and barrel housing installed on a 2”pipe with optional bracket (B6
carbon steel or B7 Stainless Steel 316L) for sensor W
Figure 8: Model 266HSH with 1/2-14 NPT female process connection and barrel housing installed on a 2”pipe with optional bracket (B6
carbon steel or B7 Stainless Steel 316L) for sensor W
91 (3.58)
72 (2.83)

ABB 266HSH Specifications

General

Type	Pressure Transmitter
Material	Stainless Steel
Temperature Range	-40 to 85°C (-40 to 185°F)
Output Signal	4-20 mA
Process Connection	1/2 in. NPT
Ingress Protection	IP67
Electrical Connection	1/2 in. NPT, M20 x 1.5
