ABB 8215 U-500 - Alarm Call Function

Operating Instructions
Busch-AudioWorld
®
Operation
Operating Instructions | 1473-1-7955 — 9 —
Pos: 28 /#Neustruktur#/Online-Dokumentation (+KNX)/Überschriften (--> Für alle Dokumente <--)/3. Ebene/U - Z/Weckfunktion @ 22\mod _1331558252943_15.doc x @ 202853 @ 3 @ 1
4.3.3 Alarm call function
Pos: 29 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Bedienu ng/AudioVideo/Ei nstellungen Setup/Ei nstellungen Weckf unktion - 8215 @ 21\mod_133154 7204095_15.docx @ 202573 @ @ 1
Fig. 5: Alarm call function
We recommend that you set the alarm call function always at the same time. To set the alarm call function after
the setup is no longer possible. To activate the alarm call function you need to carry out the setup again.
If this function is not relevant for you, you can change to the next menu item by pressing the "plus or minus"
button.
In step 3 "Alarm call function" the following functions become available:
No. Function
1 Alarm call function
- When confirming with the Prog button you switch to menu item "Alarm call function".
2 Setting the alarm call function to Off/On
- Set the alarm call function to Off/On with the "plus / minus" buttons.
- Confirm your selection with the "PROG" button. When you have selected the alarm call function, you
simultaneously switch to the next processing step.
3 Setting the alarm call function to "On":
Set the hours
- Set the hours with the "plus / minus" buttons.
- Confirm the hours entered with the PROG button.
Setting the minutes
- Set the minutes with the "plus / minus" buttons.
- Confirm the minutes by pressing the PROG button. You simultaneously switch to the next processing
step.
Pos: 30 /#Neustruktur#/Online-Dokumentation (+KNX)/Steuermodule - Online-Dokumentation (--> Für alle Dokumente <--)/++++++++++++ Seitenumbruch ++++++++++++ @ 9\mod_126889866 8093_0.docx @ 52149 @ @ 1
PROG
MENU
UHR/WECK
3
