7.3 Electrical connection
Pos: 86 /#Neustruktur #/Online-Dokumen tation (+KNX)/Anschl uss/AudioVideo/Ansc hluss - 8215 @ 21\mod_133 0683719780_15.doc x @ 199979 @ @ 1
Fig. 24: Electrical connection
No. Function
A
Option, simultaneous switch-on with room light
B Option, connection of an external antenna
C Variation: When connecting fluorescent or energy-saving lamps a 2-pole switch is necessary
L
N
