Operation Manual / 1 Introduction

1 Introduction / 1.2 Symbols, definitions

Definition of pictograms

The following pictograms can occur in this document. These point out actions that must be

taken in accordance with the meaning of the relevant pictogram.

Pictogram Meaning

Tighten with specified torque

Tighten over specified tightening angle

Hand-tight, tighten without tools

Oil

Apply screw locking paste (e.g. Loctite)

Apply high-temperature grease

Apply other paste in accordance with specifications

Oil free, grease free and dry

Affix

Measure

Note

Visually inspect

Please note text for numbered work step.

See document

Dispose of in an environmentally compatible, professional way and in compliance

with locally applicable regulations.

Table1: Definition of pictograms
