OctetsRange of valuesMeaning
21 - 0xffffschedule version
21 - 0xffffsubschema identifier
41 - 0xffffffffperiod
sequence 1
sequence i
sequence m
4 * l, I = 1, 2, 3, ...0end of sub-schedule
B.5.3 Sequence
OctetsRange of valuesMeaning
40 - 0xffffffffstart time
2unusedmaximum duration
3see followingelement description 1
3see followingelement description i
3see followingelement description x
2 * I, I = 1, 2, 3, ...0end of sequence
B.5.4 Sequence Element
OctetsRange of valuesMeaning
10xB0 + priorityelement type: CD2
2node.selectorDLCEP address
Parameters consisting of several bytes must have the Motorola Big-Endian format.
2PAA114135-610 104
B Technical Reference
B.5 Data Format for Schedule Domain
