2.5 Interfaces and Display Elements
Figure 2.5: LD 810HSE Ex
2.5.1 Status Indicators - LEDs
The Linking Device is equipped with 8 LEDs on its front side:
Figure 2.6: Status Indicators - LEDs
2PAA114135-610 37
2 Hardware Installation
2.5 Interfaces and Display Elements
