USER’S MANUAL
17/26
Motor details
Motor type code:
ABB M2VA 63 B 4 (3GVA 062 142-ASC)
Motor nameplate:
AC input (supply) connection
U1 ~ 115VAC or 230VAC (L, N, PE)
The democase can be used with both 115V and 230V supply. It is important to make sure that the input
voltage switch (115V/230V) is in the correct position for the supply. For example, if you are using 230V
supply, then “230V” should be visible in the switch. If the switch is set incorrectly you will burn the fuse.
Degree of protection
Drive: IP21
Motor: IP55
Complete demo: IP20
Ambient conditions
The demo is designed for demonstration purposes and for indoor use only.
Ambient temperature:
- Transport: -40 to +70 °C
- Storage: -40 to +70 °C
- Operation: -15 to +40 °C, no frost allowed
Altitude:
- 0 to 4,000 m without an effect on demo operation
Relative humidity:
- 5 to 95%, no condensation allowed
For more detailed information, refer to the drive Hardware Manual.
Parameter
ACH580 parameter
Value
Motor type
99.03 Motor type
AM
Rated current In
99.06 Motor nominal current
1.2 A
Rated voltage Un
99.07 Motor nominal voltage
230.0 V
Frequency Fn
99.08 Motor nominal frequency
50.0 Hz
Rated speed
99.09 Motor nominal speed
1360 rpm
Rated power Pn
99.10 Motor nominal power
0.18 kW
COS φ
99.11 Motor nominal cosfii
0.71
Rated torque
99.12 Motor nominal torque
0.82 Nm
