ABB ACQ810 - PLC Logic


Quickstart Guide


ABB PLC and drives integration using Modbus RTU


ModbusRTU‐27‐ PLCanddrivesintegration

PLClogic
ThefollowingprogramhandlesaS
peedcontroldriveapplication.
Compileyourproject,choose“Rebuildall”fromthe“Project”menu.

Right‐click “PLC_PRG” in the “POUs” tab and choose “Convert Object”. Choose Target Language “FBD”  and click
“OK”.
 
Right‐clickinthePOUsfieldandchoose“AddObject”.SetTypeof POUto“Program”andLanguageofthePOUto
“FBD”,givethenewProgramasuitablenameandclick“OK”.
 
