Layout
￭
Frame sizes R0...R1
4
5
6
7
8
11
9
3
2
1
10
EMC filter grounding screw
1)
7Input power connection terminal1
PE connection (motor)8Control panel, display and status LED2
Fixed control terminals9Motor connection terminal3
Front cover10Cooling fan4
Model information label11Panel and PC tool port (RJ45)5
Type designation label6
1)
Drive types ACS180-04N-xxxx-x do not have this EMC screw.
