65 ACS2000 AFE 1MVA UM 3BHS297030 ZAB E01 REV. J
Communication with AMC circuit board
The fieldbus adapter is connected to channel 0 of
the AMC circuit board via optical fibers.
Location
The fieldbus adapter is DIN rail-mounted inside the
control compartment (3-10: 1).
The indicated mounting position may vary depend-
ing on the number of optional devices present on
the swing frame.
To identify the adapter type installed in
the drive, see the applicable Wiring dia-
grams.
INU
AMC circuit board
Higher-level control system
Fieldbus
adapter
DDCS
3-10 Location of fieldbus
and pulse encoder
interface
