Electrical installation
75
Note: Location of the X41 terminal block varies according to the drive frame size,
see page 67.
Note: Maximum cable length between AGPS terminal block X2 and drive terminal
block is restricted to 10 m.
For technical data see section AGPS-11C in chapter Technical data.
