ABB DCS 500B

DCS500 Pin and Parameter list
A 69
FIELDBUS_PAR.4
Parameter of FIELDBUS-function block. (S12/16 ).
Fieldbus parameter with adapter specific function
PROFIBUS (NPBA-02) BIT RATE SELECT (0) 9.6KBIT
(1) 19.2KBIT
(2) 93.75KBIT
(3) 187.5KBIT
(4) 500KBIT
(5) 1.5MBIT
(6) AUTO
PROFIBUS (NPBA-12) NODE NUMBER 2 to 126
AC31 STATION NUMBER 0 … 5 (Word Mode)
0 … 57 (Binary Mode)
MODBUS BAUD RATE (0) 1200
(1) 2400
(2) 4800
(3) 9600
(4) 19200
MODBUS+ Good Msg read only
CANopen BAUD RATE (0) 1 Mbit/s
(1) 500 kbit/s
(2) 250 kbit/s
(3) 125 kbit/s
(4) 100 kbit/s
(5) 50 kbit/s
(6) 20 kbit/s
(7) 10 kbit/s
DeviceNet STATUS read only
(0) SELF TEST
(1) NO CONNECT
(2) CONNECTED
(3) TIMEOUT
(4) DUP. MAC ERR
(5) BUS_OFF
(6) COM. ERROR
(7) WRONG ASMBLY
4004 FB_P: I2 SC: 1 HL: 32767 LL: 0 D: 0 U: -
