ABB DCS 500B

DCS500 Pin and Parameter list
A 70
FIELDBUS_PAR.5
Parameter of FIELDBUS-function block. (S12/16 ).
Fieldbus parameter with adapter specific function
PROFIBUS (NPBA-02) NO. OF DATA SETS 1 to 4
PROFIBUS (NPBA-12) NO. OF DATA SETS 1 to 4
AC31 ADDR INDEX (0) LOWER
(1) UPPER
MODBUS PARITY (0) EVEN
(1) ODD
(2) NONE 2 STOP BIT;
(3) NONE 1 STOP BIT
MODBUS+ Bad Msg read only
CANopen COMM PROFILE (0) CSA 2.8/3.0
(1) ABB DRIVES
(2) TRANSPARENT
DeviceNet PROFILE SELECTION (0) ABB DRIVES
(1) CSA 2.8/3.0
4005 FB_P: I2 SC: 1 HL: 32767 LL: 0 D: 0 U: -
FIELDBUS_PAR.6
Parameter of FIELDBUS-function block. (S12/16 ).
Fieldbus parameter with adapter specific function
PROFIBUS (NPBA-02) DATA SET OFFSET 0 to 255
PROFIBUS (NPBA-12) DATA SET INDEX (0) FBA DSET 1
(1) FBA DSET 10
AC31 DATA SETS 1; 2; 3
MODBUS GOOD MESSAGES read only
MODBUS+ GD Out 1 0 ... 96
CANopen CUT-OFF TIMEOUT 0 to 255
DeviceNet POLL OUTPUT SELECT (0) BASIC SPEED
(1) TRANSPARENT
(2) PARAMETERS
(3) MUL. DATASETS
4006 FB_P: I2 SC: 1 HL: 32767 LL: 0 D: 0 U: -
