ABB DCS 500B

DCS500 Pin and Parameter list
A 71
FIELDBUS_PAR.7
Parameter of FIELDBUS-function block. (S12/16 ).
Fieldbus parameter with adapter specific function
PROFIBUS (NPBA-02) CUT-OFF TIMEOUT 0 to 255
PROFIBUS (NPBA-12) CUT-OFF TIMEOUT 0 to 255
AC31 DATA SET1 CONST 0 … 32767 (1 = 6ms)
MODBUS BAD MESSAGES read only
MODBUS+ GD Out 2 0 ... 96
CANopen STATUS read only
(0) SELF TEST
(1) RX Q OVERRUN
(2) CAN OVERRUN
(3) BUS OFF
(4) ERROR SET
(5) ERROR RESET
(6) TX Q OVERRUN
(7) DISCONNECTED
(8) STARTED
(9) STOPPED
(10) G FAILS
(11) PRE-OPERAT
(12) RESET COMM.
(13) RESET NODE
DeviceNet POLL/COS INPUT SEL (0) BASIC SPEED
(1) TRANSPARENT
(2) PARAMETERS
(3) MUL. DATASETS
4007 FB_P: I2 SC: 1 HL: 32767 LL: 0 D: 0 U: -
FIELDBUS_PAR.8
Parameter of FIELDBUS-function block. (S12/16 ).
Fieldbus parameter with adapter specific function
PROFIBUS (NPBA-02) COMM PROFILE (0) ABB DRIVES
(1) CSA 2.8/3.0
PROFIBUS (NPBA-12) COMM PROFILE (0) ABB DRIVES
(1) CSA 2.8/3.0
AC31 DATA SET2 CONST 0 … 32767 (1 = 6ms)
MODBUS DDCS CHANNEL (0) CH0'
(1) CH3
MODBUS+ GD Out 3 0 ... 96
CANopen DATA SET INDEX (0) FBA D SET 1
(1) FBA D SET 10
DeviceNet COS DATA OUTPUT (0) BASIC SPEED
(1) TRANSPARENT
(2) PARAMETERS
(3) MUL. DATASETS
4008 FB_P: I2 SC: 1 HL: 32767 LL: 0 D: 0 U: -
