ABB DCS 500B

DCS500 Pin and Parameter list
A 72
FIELDBUS_PAR.9
Parameter of FIELDBUS-function block. (S12/16 ).
Fieldbus parameter with adapter specific function
PROFIBUS (NPBA-02)
Software > V2.3 CONTROL ZERO MODE (0) STOP
(1) FREEZE
PROFIBUS (NPBA-12) CONTROL ZERO MODE (0) STOP
(1) FREEZE
AC31 DATA SET3 CONST 0 … 32767 (1 = 6ms)
MODBUS not used
MODBUS+ GD In 1 Stn 0 ... 64
CANopen NO. OF D SETS 1 or 2
DeviceNet BIT STROBE OUTPUT (0) BASIC SPEED
(1) TRANSPARENT
(2) PARAMETERS
4009 FB_P: I2 SC: 1 HL: 32767 LL: 0 D: 0 U: -
FIELDBUS_PAR.10
Parameter of FIELDBUS-function block. (S12/16 ).
Fieldbus parameter with adapter specific function
PROFIBUS not used
AC31 DATA SET OFFSET 1 … 255
MODBUS not used
MODBUS+ GD In 1 Wrd 0 ... 31
CANopen not used
DeviceNet DATASET INDEXES (0) FBA DSET 1
(1) FBA DSET 10
4010 FB_P: I2 SC: 1 HL: 32767 LL: 0 D: 0 U: -
FIELDBUS_PAR.11
Parameter of FIELDBUS-function block. (S12/16 ).
Fieldbus parameter with adapter specific function
PROFIBUS not used
AC31 not used
MODBUS not used
MODBUS+ GD In2 Stn 0 ... 64
CANopen not used
DeviceNet SPEED REF. SCALE 0 … 32767
4011 FB_P: I2 SC: 1 HL: 32767 LL: 0 D: 0 U: -
FIELDBUS_PAR.12
Parameter of FIELDBUS-function block. (S12/16 ).
Fieldbus parameter with adapter specific function
PROFIBUS not used
AC31 not used
MODBUS not used
MODBUS+ GD In2 Wrd 0 ... 31
CANopen not used
DeviceNet SPEED ACT. SCALE 0 … 32767
4012 FB_P: I2 SC: 1 HL: 32767 LL: 0 D: 0 U: -
