Chapter 2 - Start-Up Instructions
DCS 600 Operating Instructions IV F 2 - 5
• Programmable values (can be changed for monitoring of other signals)
Cyclic transmission time for the first three programmable values is every 2 ms, for all
other values every 8 ms:
Cyclic transmission Enter pa- Cyclic trans- Default
from
--> to rameter in mission time
AMC --> CON-2 95.01 2 ms 3.11 CURRENT REF
AMC --> CON-2 95.02 2 ms 45.01 FLUX REF
AMC --> CON-2 95.03 2 ms 45.03 EMF REF
AMC --> CON-2 95.04 8 ms 0
AMC --> CON-2 95.05 8 ms 0
AMC --> CON-2 95.06 8 ms 0
AMC --> CON-2 95.07 8 ms 0
AMC --> CON-2 95.08 8 ms 0
AMC --> CON-2 95.09 8 ms 0
AMC --> CON-2 95.10 8 ms 0
AMC --> CON-2 95.11 8 ms 0
AMC --> CON-2 95.12 8 ms 0
AMC --> CON-2 95.13 8 ms 0
CON-2 --> AMC 94.01 2 ms 3.13 ARM ALPHA
CON-2 --> AMC 94.02 2 ms 1.15 CONV CUR
CON-2 --> AMC 94.03 2 ms 3.12 CUR REF3
CON-2 --> AMC 94.04 8 ms 1.11 RL MAINS VOLT ACT
CON-2 --> AMC 94.05 8 ms 1.13 RL ARM VOLT ACT
CON-2 --> AMC 94.06 8 ms 1.28 LOAD CUR ACT FILT
CON-2 --> AMC 94.07 8 ms 1.17 RL EMF VOLT ACT
CON-2 --> AMC 94.08 8 ms 1.24 HEATSINK TEMP
CON-2 --> AMC 94.09 8 ms 1.20 MOT1 CALC TEMP
CON-2 --> AMC 94.10 8 ms 3.17 FIELD CUR REF M1
CON-2 --> AMC 94.11 8 ms 3.19 REL FIELD CUR M1
For example: Display of actual field current value 3.19 in 8 ms ⇒ 94.11 = 3.19.
Then call for display of Parameter 3.19.
