9. Model overview
HD5-B-xxx enabling device with integrated AS-i technology are described below.
Custom versions
• Type name: HD5-B-901
• Item number: 2TLA920502R0001 / 2TLA920502R0002
Position
number
Function
Additional information
1
Enabling button
2
Emergency stop button
Feedback LED integrated into emergency stop
button
3
Additional button 1
4
---------------------------------------------
5
Additional button 3
6
Additional button 4
7
Red signal LED
8
Green signal LED
9
Home position detector
only possible with the HD5-M-001 holder
10
---------------------------------------------
11
Assist light (flashlight)
12
Vibration
13
Permanent connection
2x0.75mm² spiral cable
