11. TECHNICAL DATA
Manufacturer
Address
ABB AB
JOKAB SAFETY
Varlabergsvägen 11
SE-434 39 Kungsbacka
Sweden
Power supply
Operational voltage
30 VDC, AS-i Bus, tolerance 26 - 31,6 VDC
Overall power consumption
<150 mA
General
Protection class
IP65
Ambient temperature for during operation
-10°C (no buildup of ice) up to +55°C ( no direct sunlight)
Ambient temperature for storage
-20°C (no buildup of ice) up to
+70°C (no direct sunlight)
Dimensions
See drawing in section 12 “dimensions”
Weight
approx. 200 g without connection cable
Material
Housing: Fiberglass reinforced plastic, PPH G30
Operating buttons: TPE
Actuating force
enabling button
approx. 20 N, 1  2
approx. 45 N, 2  3
Actuating force
additional buttons
approx. 3 N, additional buttons 1 and 2
approx. 7 N, additional buttons 3 and 4
Mechanical /electrical durability of
enabling button
1 x 10
6
switching cycles, position 1  position 2
1 x 10
5
switching cycles, position 2  position 3
Mechanical reliability B
10D,
enabling button
B
10D
: 2 x 10
6
, position 1  position 2  position 1
B
10D
: 968,000, position 1  position 3  position 1
Mechanical /electrical durability of
emergency stop button
5 x 10
4
switching cycles
Mechanical reliability B
10d,
emergency stop button
B
10D
: 250,000
Mechanical durability of
additional button 1
2 x 10
6
switching cycles
Mechanical durability of
additional buttons 2/3/4
5 x 10
4
switching cycles
Connection
Connection cable 2x0.75mm², PUR
