AS-i data
The enabling device with integrated AS-i technology contains up to three slaves, depending on the
configuration.
The following bit description relates to functions that are generally possible, and is set out in detail in the
data sheet enclosed with the product (or available from ABB), depending on the configuration.
Custom versions HD5-B-901
(up to 10 tuning devices may be used on one AS-i cable)
Slave
I/O type
Bit
Value
Description
S-7.B.1.E
Address 01
upon
delivery
Safe code1
D 0
emergency stop button
Safe code1
D 1
Safe code2
D 2
Safe code2
D 3
Output
Non safe
D 0
0
feedback LED in emergency stop button, OFF
1
feedback LED in emergency stop button, ON
S-0.B.2.E
Address 02
upon
delivery
Safe code1
D 0
enabling button
Safe code1
D 1
Safe code2
D 2
Safe code2
D 3
S-7.0.3.E
Address 03
upon
delivery
Input
Non safe
DI 0
0
additional button 1 (tab), not actuated
1
additional button 1 (tab), actuated
DI 1
0
home position sensor, enabling device not hung up in holder
1
home position sensor, enabling device hung up in holder
DI 2
0
additional button 3 (lift), not actuated
1
additional button 3 (lift), actuated
DI 3
0
additional button 4 (lower), not actuated
1
additional button 4 (lower), actuated
Output
Non safe
DO 0
0
green signal LED, OFF
1
green signal LED, ON
DO 1
0
red signal LED, OFF
1
red signal LED, ON
DO 2
0
assist light (flashlight), OFF
1
assist light (flashlight), ON
DO 3
0
vibration alarm, OFF
1
vibration alarm, ON
