ABB HD5-B-901 - Information on Positions

2CDC172114M0201 20 www.abb.com/lowvoltage
2019-09-06 V1.3
No. 1,
enabling button
No. 2,
emergency stop button
Feedback LED integrated
Information on positions
No. 7, red signal LED
No.3,
additional button 1
No. 5,
additional button 3
No. 11, Assist light
(flashlight)
No.6,
additional button 4
No. 13, connection
No. 8, green signal LED
integrated into housing
No. 9, home position sensor
No. 10, ------------------------
No. 12, vibration motor
