ABB HT611036 Instruction Manual

Operation Manual / 4 Product description / A150-M56/66/57/67 -
A155-M..
17 Spare parts / 17.3 View of turbocharger with part numbers
© Copyright 2020 ABB. All rights reserved. HZTL4032_EN Rev.P March 2020
Part number Designation
-- Cartridge group
42012 (in customer spare part set) O-ring
42167 Orifice
42170 (option) Bearing casing insulation
42190 Expansion sleeve
42191 Threaded rod
42193 Centering bush
42195 (in the customer spare part set) O-ring
42196 Oil orifice
42200 (in the customer spare part set) O-ring
42201 Clamping nut
51000 Turbine casing
51002 Fastening strip
51010 Bearing casing insulation
51105* Metal C-ring
51500 Burst protection
56001 Nozzle ring
56005 Lamellar sealing ring
57002 Gas outlet flange
57003* Metal C-ring
57210 Burst ring
61001 Gas outlet casing
61002 (in the customer spare part set) Gasket
61301* Support
72000 Compressor casing
72011 Hexagon-head screw
72012 Fastening strip
72060 Hood
72061 Insulating bush
77000 Wall insert
77005 (in customer spare part set) O-ring
79000 Diffuser
79040 Fixing disc
79041 (in the customer spare part set) Counter-sunk screw
81000 Filter silencer
81010 (in the customer spare part set) O-ring
82000 Air suction branch
82010 (in the customer spare part set) O-ring
86505* Speed sensor
86515* Cable connector
86526* F/I converter
86528* Tachometer
Table76: Spare parts list
* Depending on the specification of the turbocharger
Page 161 / 171
