Operation Manual / 2 Safety / A130 - A155
1 Safety / 1.13 Safe operation
© Copyright 2017 ABB. All rights reserved. HZTL4022_EN Revision E May 2017
WARNING
Burst protection and insulation
Operation without burst protection and insulation or with the wrong com-
bination of burst protection and insulation can cause serious injuries to per-
sons or even fatal accidents.
u Only operate the turbocharger with burst protection fitted and insulation
fitted in one of the following, permitted variants.
Fig.5
Variant A Insulation(01) with integrated burst protection from ABB Turbo Systems.
Variant B Burst protection(03) and insulation (02)from ABB Turbo Systems.
Variant C Burst protection(03) from ABB Turbo Systems with appropriate insulation
from the enginebuilder.
Page 14 / 18
