Specifications
Electromagnetic compatibility
Conducted transients
Electrostatic discharge
(IEC 61000-4-2, EN 61000-4-2)
Contact: ±6 kV
Air: ±8 kV
Magnetic and electromagnetic
fields
Power frequency magnetic
field (IEC 61000-4-8, EN
61000-4-8)
Pulse magnetic field (IEC
61000-4-9, EN 61000-4-9)
Damped oscillatory magnetic
field, 0.1 MHz and 1 MHz (IEC
61000-4-10, EN 61000-4-10)
Radiated radio-frequency
electromagnetic field, 80 MHz
to 1GHz (IEC 61000-4-3)
Radiated radio-frequency field,
900 ±5 MHz (ENV 50204)
Radio-frequency common
mode, amplitude modulated,
0.15 MHz to 80 MHz (IEC
61000-4-6)
Continuous: 30 A
RMS
/m
Short duration: 300 A
RMS
/m
Peak value: 300 A/m
Peak value: 30 A/m
Unmodulated RMS: 10 V/m
Amplitude modulated: 80% AM (1 kHz)
Unmodulated RMS: 10 V/m
Pulse modulated: Duty cycle 50%, Rep. cycle 200 Hz
Unmodulated RMS: 10 V
Amplitude modulated: 80% AM (1 kHz)
Source impedance: 150 !
Emission test RF radiated fields,
30 MHz to 1000 MHz
(EN 55011)
Class A
Mounting Occupies a single slot in a standard module mounting unit.
Tabl e 1-4. Specif ication s
(continued)
Property Characteristic/Value
Test
Common
Mode
Normal
Mode
Voltage/current surge (1.2/50 µS to 8/20 µS)
(IEC 61000-4-5, EN 61000-4-5)
±2 kV
P
±1 kV
P
Fast transient bursts (IEC 61000-4-4, EN
61000-4-4)
±2 kV
P
N/A
Damped oscillatory wave, 0.1 MHz and 1
MHz (IEC 61000-4-12, EN 61000-4-12)
±1 kV
P
±0.5 kV
P
Ring wave (IEC 61000-4-12, EN 61000-4-12) ±2 kV
P
±1 kV
P
