ABB Industrial IT enabled REX 521 - Single-pole power outputs (PO); Signalling outputs (SO)

20
1MRS 751108-MUM
3URWHFWLRQ5HOD\
Technical Reference Manual, General
5(;
doubpolerex
)LJ +LJKVSHHGVLQJOHSROHSRZHURXWSXW+632
 6LQJOHSROHSRZHURXWSXWV32
The single-pole power outputs PO1...3 are outputs where the object to be controlled
is connected in series with two heavy-duty output relay contacts, see the Figure
4.1.8.2.-1 below. These outputs can be used for tripping purposes and for circuit
breaker and disconnector control. Two singe-pole outputs may be used to obtain
another double-pole output.
PO1connrex
)LJ 6LQJOHSROHSRZHURXWSXWV32
 6LJQDOOLQJRXWSXWV62
The signalling relay outputs (SO1 and SO2) are not heavy-duty outputs and thus
they cannot be used for controlling, for example, a circuit breaker. Available relay
contacts are Normally Open/Normally Closed type (NO/NC), see the Figure
4.1.8.3.-1 below. These outputs can be used for alarming and other signalling
purposes.
NoncRex
)LJ 6LJQDOOLQJRXWSXW62
+
-
CB
HSPO1
+
-
CB
PO1...3
NO/NC
e.g.
SO1
