• Pdf-format template (Label1MRS151300.pdf) can be used when you use
Acrobat Reader®
1
and only want to print the signal names on the label.
2. Depending on printer, the print size may vary: test print the label on paper
before printing it on transparency. To adjust the print height to the maximum
height of the label (106 mm), use the zoom option of the printer settings.
3. Print the label on the blank transparency. It is recommended to write and print
two labels at the same time since the templates contain two labels to fill the
signal names in.
Use only laser printers for printing. Ink jet printers are not suitable for
printing on label transparencies.
4. Put the label in the pocket on the front panel of REX 521.
1. Acrobat Reader® is registered trademark of Adobe Systems Inc.
!
