38
1MRS 751108-MUM
3URWHFWLRQ5HOD\
Technical Reference Manual, General
5(;
7DEOH 3RZHURXWSXWV
Max. system voltage 250 V ac/dc
Continuous carry 5 A
Make and carry for 0.5 s 30 A
Make and carry for 3 s 15 A
Breaking capacity when control
circuit time constant L/R <40 ms, at
48/110/220 V dc
5 A/3 A/1 A
Minimum contact load 100 mA, 24 V ac/dc (2.4 VA)
TCS (Trip-circuit
supervision)
Control voltage
range
20…265 V ac/dc
Current drain
through the
supervision
circuit
approx. 1.5 mA (0.99…1.72 mA)
Minimum voltage
(threshold) over
a contact
20 V ac/dc (15…20 V)
7DEOH (QYLURQPHQWDOFRQGLWLRQV
Specified service temperature range -10…+55°C
Transport and storage temperature range -40…+70°C
Enclosure class Front side, flush-mounted IP 54
Rear side, connection terminals IP 20
Dry heat test according to IEC 60068-2-2
Dry cold test according to IEC 60068-2-1
Damp heat test, cyclic according to IEC 60068-2-30,
r.h. >93%, T = 25…55°C
Storage temperature tests according to IEC 60068-2-48
7DEOH 6WDQGDUGWHVWV
Insulation tests Dielectric test
IEC 60255-5
Test voltage 2 kV, 50 Hz, 1 min.
Impulse voltage
test
IEC 60255-5
Test voltage 5 kV, unipolar impulses,
waveform 1,2/50 µs, source
energy 0.5 J
Insulation
resistance
measurements
IEC 60255-5
Insulation resistance > 100 MΩ, 500 V dc
Mechanical tests Vibration tests (sinusoidal) IEC 60255-21-1, class I
Shock and bump test IEC 60255-21-2, class I
Seismic test IEC 60255-21-3, class 2
7DEOH (OHFWURPDJQHWLFFRPSDWLELOLW\WHVWV
The EMC immunity test level fulfills the requirements listed below
1 MHz burst disturbance test, class
III, IEC 60255-22-1
common mode 2.5 kV
differential mode 1.0 kV
Electrostatic discharge test,
class III
IEC 61000-4-2 and 60255-22-2
for contact discharge 6 kV
for air discharge 8 kV
Radio frequency interference test conducted, common mode
IEC 61000-4-6, IEC 60255-22-6
10 V (rms),
f = 150 kHz…80 MHz
radiated, amplitude-modulated
IEC 61000-4-3, IEC 60255-22-3
10 V/m (rms),
f = 80…1000 MHz
radiated, pulse-modulated
ENV 50204, IEC 60255-22-3
10 V/m,
f = 900 MHz
