ABB IRB 2600ID - Page 77

IRB 2600 standard
250
240
260
360
300
120 200
200
260
300
280
180
A
B
D
380
200
C
IRB 2600 -1.65 = 700 IRB 2600 -1.85 = 900
xx0900000189
Max load DMax load
A+C
Max load CMax load BMax load AVariant
35 kg10 kg10 kg1 kg10 kgIRB 2600-20/1.65
IRB 2600 Type C-
20/1.65
IRB 2600-12/1.85
35 kg15 kg15 kg1 kg15 kgIRB 2600-12/1.65
IRB 2600 Type C-
12/1.65
Continues on next page
Product manual - IRB 2600 77
3HAC035504-001 Revision: AD
