ABB IS-limiter User Manual

7
2.2 I
s
-limiter
TM
switch
Electrical data
Rated voltage Rated current
Rated power frequency
withstand voltage
Rated lightning impulse
withstand voltage
Weight
I
s
-limiter
TM
insert holder I
s
-limiter
TM
insert
kV A kV kVp Kg Kg
36 1250,2000,2500
1)
70 170 60 42
1)
With cooling fan installed in panel
2.3 Tripping device and auxiliary circuits
Electrical data
Device
Power consumption
1)
Rated supply voltages
AC
VA
DC
W
AC (f=50/60 Hz)
V
DC
V
Tripping device 80 - 110, 220 -
Auxiliary circuits
(blocking magnet, auxiliary relay)
- 60 110, 220 110, 220
1)
approximate values
