ABB KPM KB2 - Appendix 3: KB Model Selection

34
Appendix 3: KPM KB2 model selection
SHEET BREAK
DETECTORS
Type
Order Code
Description
K
B
6
KB/6 Sheet Break Detector, 6 meters (20ft) Fiber Optic Cable,
1,5m Sensor Head rod
KB2 Display Unit, 85...264VAC, 2 x RELAY outputs included
K
B
6P
KB/6 Sheet Break Detector, 6 meters (20ft) Fiber Optic Cable,
1,5m Sensor Head rod
KB2 Display Unit, 24VDC, 4 x RELAY outputs included
K
B
9
KB/9 Sheet Break Detector, 9 meters (30ft) Fiber Optic Cable,
1,5m Sensor Head rod
KB2 Display Unit, 85...264VAC, 2 x RELAY outputs included
K
B
9P
KB/9 Sheet Break Detector, 9 meters (30ft) Fiber Optic Cable,
1,5m Sensor Head rod
KB2 Display Unit, 24VDC, 4 x RELAY outputs included
K
B
12
KB/12 Sheet Break Detector, 12 meters (40ft) Fiber Optic Cable,
1,5m Sensor Head rod
KB2 Display Unit, 85...264VAC, 2 x RELAY outputs included
K
B
12P
KB/12 Sheet Break Detector, 12 meters (40ft) Fiber Optic Cable,
1,5m Sensor Head rod
KB2 Display Unit, 24VDC, 4 x RELAY outputs included
Flexible Conduit for Fiber optic cable
N
No Conduit
C
Full Flexible SS316 Conduit 25mm (1") with Connectors
Mounting Rack
N
No adjustable mounting rack, only mounting clamps
R
Adjustable Mounting Rack
P
PosiEye Adaptor with standard 1,5m rod
W
Posi Eye Adaptor, short rod with screw mount to posi Eye tube.
Analog output
N
No Analog outputs for DCS trending ( Analog outputs not needed for
break alarm)
A
3x 4-20 mA outputs for DCS trending
KB-Connection PC Program
N
No KB-Connection PC Program
C
KB-Connection PC Program on CD disk
RS485 / USB Converter for PC program
N
No RS485 / USB Converter for PC program
R
RS485 / USB Converter for PC program, Rack mounting
T
High temperature fiber optics cable max. 220C
