PGC5000 Series Service Instructions 5 Diagnostics and troubleshooting
SI/PGC5000-EN, Rev B 18
amber off off off temperature zone setup
amber off amber off temperature conversion setup
amber amber off off A/D converter setup
amber amber amber off number valves detection
off amber red off reload CANopen from EEPROM
off red red off CAN PDO setup
red off red off start DTC initialization
red red off off valve testing and initialization
red red red off safety switch testing initialization
amber off green off PIC initialization
amber off red off signal testing initialization
amber amber green off purge testing initialization
amber amber red off miscellaneous initialization
CR3 is set red and CR4 is set amber upon receiving an NMT reset command from the OC. If the DSP can successfully reset, all
the LEDs will be turned off and then altered again during normal execution.
Specific CR4 functions: After the DTC becomes operational, unhandled interrupts might occur. These are reflected by a staying
solid red or blinking CR4.
A blinking red CR4 will blink for a count, pause, and then blink repeat the count again (continuously). Count the blinks between
pauses and determine the cause using the following list:
Blinks
Source
1 (unused)
2 (rfu)
3 non-maskable
4 illegal operation
5 data logger
6 RTOS
7 Emulation
8 CPU timer 1
9 CPU timer 2
When a solid re CR4 occurs, the status of CR1 through 3 identify the interrupt source:
CR1 CR2 CR3 CR4
Source
off off amber red INT1.x
off amber off red INT2.x
off amber amber red INT3.x
amber off off red INT4.x
amber off amber red INT5.x
amber amber off red INT6.x
amber amber amber red INT7.x
off off red red (rfu)
off red off red (rfu)
off red red red reprogram flash memory
red off off red erase flash memory
red off red red user trap
red red off red test
red red red red misc. disabled source
green green red red SCI-A RX
green red green red SCI-A TX
green red red red SCI-B RX
red green green red SCI-B TX
red green red red eCAN 0
red red green red eCAN 1
