ABB UPS PRODUCTS AND SOLUTIONS
4.6.2 UPS status menu
By pressing on the UPS status menu, the next
UPS status menu tree is displayed.
The content of UPS status menu tree is same as
the default UPS status summary menu.
By pressing ESC for more than 3 seconds, the last
main menu tree is displayed.
—
22 Main menu
—
23 UPS status menu
In addition to the default UPS status summary
screen, the user has access to useful information
about the UPS status, including various detailed
measurements, previous event records and the
UPS identification. The settings can be changed
to optimize the UPS for and by the user.
4.6.1 Main menu
In the default UPS status summary screen,
when pressing or for more than 3 seconds,
detailed information about alarm, battery or
system status is displayed.
In the default UPS status summary screen, press
ESC for more than 3 seconds to return to the main
menu tree. The main menu tree has six branches:
UPS status menu, Measurement menu, Event log
menu, Control menu, Identification menu and
Settings menu.
—
