ABB UPS PRODUCTS AND SOLUTIONS
—
05 UPS front panel
—
06 UPS 6 kVA S
rear panel
—
07 UPS 10 kVA S
rear panel
3.3.1 UPS 6-10 kVA S
The figures below shows the front and the rear
panel of the UPS 6-10 kVA S model.
—
3.3 General characteristics
—
05
—
06
—
07
—
Table 2: UPS 6-10kVA S model front and
rear panel connectors and ports
[reserved for future development]
EBM connector
USB
Dry IN/OUT
Parallel card
EPO
Fans
Maintenance bypass switch
Input switch
Input/Output terminals
