Fieldbus interfaces 103
Data I/O registers 3 ... 53 programmed for the VSN-700 logger:
Holding
register
FbEq (16b/32b),
scaling
Description Mirrored inverter
parameter
Config
Parameter
Name
3 16b, 10 = 1 DC voltage 101.01 158.104 Data I/O 4
4 16b, 10 = 1 Line current 101.02 158.105 Data I/O 5
5 16b, 100 = 1 Frequency 101.08 158.106 Data I/O 6
6 16b, 10 = 1 Apparent power 101.10 158.107 Data I/O 7
7 16b, 10 = 1 Power 101.10 158.108 Data I/O 8
8 16b, 10 = 1 Reactive power 101.14 158.109 Data I/O 9
9 16b, 100 = 1 CosPhi 101.16 158.110 Data I/O 10
10 16b, 10 = 1 Input current 101.30 158.111 Data I/O 11
11 16b Tripping fault 104.01 158.112 Data I/O 12
12 16b Active warning 1 104.06 158.113 Data I/O 13
13 16b Active warning 2 104.07 158.114 Data I/O 14
14 16b Active warning 3 104.08 158.115 Data I/O 15
15 16b Active warning 4 104.09 158.116 Data I/O 16
16 16b Active warning 5 104.10 158.117 Data I/O 17
17 16b Latest warning 104.16 158.118 Data I/O 18
18 16b Main status word 106.11 158.119 Data I/O 19
19 16b Cpu usage 107.11 158.120 Data I/O 20
20 32b Connection status 172.01 158.121 Data I/O 21
21 Reserved Data I/O 22
22 32b Disconnect diagnostic 172.02 158.123 Data I/O 23
23 Reserved Data I/O 24
24 32b Output power diagnostic 172.03 158.125 Data I/O 25
25 Reserved Data I/O 26
26 32b, 1 = 1 Uptime 173.01 158.127 Data I/O 27
27 Reserved Data I/O 28
28 16b, 1 = 1 Operation time 173.02 158.129 Data I/O 29
29 16b, 1 = 1 Internal fan speed 173.06 158.130 Data I/O 30
30 16b, 1 = 1 External fan 1 speed 173.07 158.131 Data I/O 31
31 16b, 1 = 1 External fan 2 speed 173.08 158.132 Data I/O 32
32 32b, 1 = 1 Grid connections 173.20 158.133 Data I/O 33
33 Reserved Data I/O 34
34 16b, 1 = 1 Control board temperature 173.23 158.135 Data I/O 35
35 16b, 1 = 1 Inverter temperature A 173.24 158.136 Data I/O 36
36 16b, 1 = 1 Inverter temperature B 173.25 158.137 Data I/O 37
37 16b, 1 = 1 Inverter temperature C 173.26 158.138 Data I/O 38
38 16b, 100 = 1 Current: [1] 174.50 158.139 Data I/O 39
39 16b, 100 = 1 Current: [2] 174.51 158.140 Data I/O 40
40 16b, 100 = 1 Current: [3] 174.52 158.141 Data I/O 41
41 16b, 100 = 1 Current: [4] 174.53 158.142 Data I/O 42
42 16b, 100 = 1 Current: [5] 174.54 158.143 Data I/O 43
43 16b, 100 = 1 Current: [6] 174.55 158.144 Data I/O 44
44 16b, 100 = 1 Current: [7] 174.56 158.145 Data I/O 45
45 16b, 100 = 1 Current: [8] 174.57 158.146 Data I/O 46
