44 Parameters
No. Name/Value/Range Description Default
FbEq (16b/32b)
114 Extension I/O module 1
114.01 Option module 1 type Activates and specifies the type of I/O extension
module 1.
None
None None 0
FIO-01 FIO-01 1
FIO-11 FIO-11 2
114.03 Option module 1 status Displays the status of I/O extension module 1. No option
No option No module detected in the specified slot. 0
No communication A module has been detected but cannot be
communicated with.
1
Unknown The module type is unknown. 2
FIO-01 An FIO-01 module has been detected and is
active.
15
FIO-11 An FIO-11 module has been detected and is
active.
20
114.05 DIO status (Visible ony when parameter 114.01 Option
module 1 type is FIO-01 or FIO-11.)
Displays the status of the digital input/outputs on
the extension module. The activation/
deactivation delays (if any are specified) are
ignored. Bit 0 indicates the status of DIO1.
Note: The number of active bits in this parameter
depends on the number of digital input/outputs on
the extension module.
Example: 00001001b = DIO1 and DIO4 are on,
remainder are off.
This parameter is read-only.
-
1 = 1
114.09 DIO1 configuration (Visible only when parameter 114.01 Option
module 1 type is FIO-01 or FIO-11.)
Selects whether DIO1 of the extension module is
used as a digital input or output.
Input
Output DIO1 is used as a digital output. 0
Input DIO1 is used as a digital input. 1
114.11 DIO1 output source (Visible only when parameter 114.01 Option
module 1 type is FIO-01 or FIO-11.)
Selects an inverter signal to be connected to
digital input/output DIO1 of the extension module
when parameter 114.09 DIO1 configuration is set
to Output.
Off
Off 0
Always On 1
Fault Relay output activation when fault. 2
No fault Relay output activation when no fault. 3
Grid connected Relay output activation when grid connected. 4
Grid not connected Relay output activation when grid not connected. 5
Power level 20% Relay output activation when output power level
over 20% of rated power.
6
Power level 40% Relay output activation when output power level
over 40% of rated power.
7
