52 Parameters
No. Name/Value/Range Description Default
FbEq (16b/32b)
124 Q ref
124.01 User Qref Writes the reactive reference value. The value
unit depends on 124.06 Q power ref type.
-
- 1 = 1 /
100 = 1
124.06 Q power ref type Sets the reactive power reference type. Qref [%]
Ireact ref [A] Reactive current reference. 0
Ireact ref [%] Reactive current reference in percent. 1
Qref [kVAr] Reactive power reference. 2
Qref [%] Reactive power reference in percents of nominal
power.
3
Phi Reactive power reference expressed as phase
angle in degrees.
4
CosPhi Reactive power reference expressed as cosinus
phi i.e. power factor.
5
Q(x) regulation curve Q(x) regulation curve. See parameter 124.30 Q(x)
curve.
8
124.11 Ireact ref max % Maximum value of reactive current reference in
percent.
105%
0 … 200% 1 = 1% /
10 = 1%
124.12 Ireact ref min % Minimum value of reactive current reference in
percent.
-105%
-200 … 0% 1 = 1% /
10 = 1%
124.13 Ireact ref lim % Output value of reactive power reference
limitation. Limitation based on 124.11 Ireact ref
max % and 124.12 Ireact ref min % values.
-
-200 … 200% 1 = 1% /
10 = 1%
124.14 Ireact ref ramp up Reactive current ramp up time in ms. 1000 ms
0 … 30000 ms 1 = 1 ms
124.15 Ireact ref ramp down Reactive current ramp down time in ms. 1000 ms
0 … 30000 ms 1 = 1 ms
124.16 Ireact ref out % Output value of reactive current reference in
percent.
-
-200 … 200% 1 = 1% /
10 = 1%
124.17 Ireact ref out Output value of reactive current in amperes. -
- 1 = 1 A /
100 = 1 A
124.18 Q pow ref out % Output value of reactive power reference in
percents of nominal power.
-
-200 … 200% 1 = 1% /
10 = 1%
124.19 Q pow ref out Output value of reactive power reference in
kVArs.
-
