Parameters 39
Parameter listing
No. Name/Value/Range Description Default
FbEq (16b/32b)
101 Actual values
101.01 DC voltage Measured DC link voltage. -
0 … 2 000 V 10 = 1 V /
100 = 1 V
101.02 Line current Calculated line current. -
0 … 100 A 10 = 1 A /
100 = 1 A
101.03 Line current % Calculated line current in percent of the nominal
current.
-
0 … 200% 1 = 1% /
10 = 1%
101.04 Active current Calculated active current. -
0 … 100 10 = 1 A /
100 = 1 A
101.05 Active current% Active current in percent of the nominal current. -
0 … 200% 1 = 1% /
10 = 1%
101.06 Reactive current Calculated reactive current. -
-100 … 100 10 = 1 A /
100 = 1 A
101.07 Reactive current % Reactive current in percent of the nominal
current.
-
-200 … 200% 1 = 1% /
10 = 1%
101.08 Frequency Measured grid frequency. -
0 … 100 Hz 100 = 1 Hz
101.09 Grid voltage Calculated average line-to-line grid voltage based
on voltage measurements.
-
0 … 2 000 V 1 = 1 V /
100 = 1 V
101.10 Apparent power Apparent output power of the inverter. -
0 … 50 10 = 1 kVA
101.11 Apparent power % Apparent output power of the inverter in percent
of the nominal output power.
-
0 … 200% 1 = 1% /
10 = 1%
101.12 Power Calculated output power. -
0 … 50 10 = 1 kW
101.13 Power % Output power in percent of the nominal power. -
0 … 200% 1 = 1% /
10 = 1%
101.14 Reactive power Calculated reactive output power. -
-100 … 100 10 = 1
