86 FEP630, FEH630 ELECTROMAGNETIC FLOWMETER | CI/FEP630/FEH630-EN REV. D

… 12 Appendix

… Torque information

Nominal diameter

[mm (in)]

Pressure rating Maximum tightening torque [Nm]

Hard / soft rubber PTFE, PFA, ETFE Ceramic carbide

** *** ** *** ** ***

DN 1350 (54 in) CL150 1036 983.7 –

–

CL300 5624 On request –

–

DN 1400 (56 in) PN 6 515 On request –

–

PN10 956.3 On request –

–

PN16 1558 On request –

–

DN 1500 (60 in) CL150 1284 1166 –

–

CL300 6139 On request –

–

DN 1600 (64 in) PN 6 570.7 On request –

–

PN10 1215 On request –

–

PN16 2171 On request –

–

DN 1800 (72 in) PN 6 708.2 On request –

–

PN10 1492 On request –

–

PN16 2398 On request –

–

DN 2000 (80 in) PN 6 857.9 On request –

–

PN10 1840 On request –

–

PN16 2860 On request –

–

** Flange material: steel.

*** Flange material: stainless steel.
