FEP630, FEH630 ELECTROMAGNETIC FLOWMETER | CI/FEP630/FEH630-EN REV. D 87

Tightening torques for transducers with design level ‘B’

Note

The specified torques are valid only for greased threads and piping that is not subject to tensile stress.

Nominal diameter [mm (in)] Pressure rating Hard / soft rubber PTFE

** [Nm] *** [Nm] ** [Nm] *** [Nm]

DN 25 (1 in) PN40 —

—

13.32 8.6

CL150 —

—

23.98 23.98

CL300 —

—

65.98 38.91

JIS 10K —

—

26.94 26.94

DN 32 (1 ¼ in) PN40 —

—

45.08 45.08

CL150 —

—

29.44 29.44

CL300 —

—

45.52 45.52

JIS 10K —

—

45.08 45.08

DN 40 (1 ½ in) PN40 —

—

56.06 56.06

CL150 —

—

36.12 36.12

CL300 —

—

73.99 73.99

JIS 10K —

—

56.06 56.06

DN 50 (1 ½ in) PN40 —

—

71.45 71.45

CL150 —

—

66.22 66.22

CL300 —

—

38.46 38.46

JIS 10K —

—

71.45 71.45

DN 65 (2 ½ in) PN16 —

—

37.02 39.1

PN40 —

—

43.03 44.62

CL150 —

—

89.93 89.93

CL300 —

—

61.21 61.21

JIS 10K —

—

37.02 39.1

DN 80 (3 in) PN40 —

—

51.9 53.59

CL150 —

—

104.6 104.6

CL300 —

—

75.54 75.54

JIS 10K —

—

45.07 47.16

DN 100 (4 in) PN16 —

—

49.68 78.19

PN40 —

—

78.24 78.19

CL150 —

—

76.2 76.2

CL300 —

—

102.6 102.6

JIS 10K —

—

49.68 78.19

DN 125 (5 in) PN16 —

—

61.4 64.14

PN40 —

—

123.7 109.6

CL150 —

—

98.05 98.05

CL300 —

—

139.4 139.4

DN 150 (6 in) PN16 —

—

81.23 85.08

PN40 —

—

162.5 133.5

CL300 —

—

111.4 111.4

** Flange material: steel.

*** Flange material: stainless steel.
