ABB ProcessMaster FEP630 - ProcessMaster Temperature Data

70 FEP630, FEH630 ELECTROMAGNETIC FLOWMETER | CI/FEP630/FEH630-EN REV. D
… 10 Specification
… ProcessMaster – Temperature data
Maximum ambient temperature depending on measuring medium temperature
Integral mount design
Flowmeter sensor in standard version
Lining material Flange material Ambient temperature range (T
amb
) Measuring medium temperature (T
medium
)
Minimum Maximum Minimum Maximum
Hard rubber Steel -10 °C (14 °F) 60 °C (140 °F) -10 °C (14 °F) 85 °C (185 °F)
Æ5 °C (23 °F)* 80 °C (176 °F) *
Hard rubber Stainless steel -15 °C (5 °F) 60 °C (140 °F) -15 °C (5 °F) 85 °C (185 °F)
-5 °C (23 °F) * 80 °C (176 °F) *
Soft rubber Steel -10 °C (14 °F) 60 °C (140 °F) -10 °C (14 °F) 60 °C (140 °F)
Soft rubber Stainless steel -15 °C (5 °F) 60 °C (140 °F) -15 °C (5 °F) 60 °C (140 °F)
PTFE Steel -10 °C (14 °F) 60 °C (140 °F) -10 °C (14 °F) 90 °C (194 °F)
45 °C (113 °F) 130 °C (266 °F)
PTFE Stainless steel -20 °C (-4 °F) 60 °C (140 °F) -25 °C (-13 °F) 90 °C (194 °F)
Æ40 °C (Æ40 °F)** 45 °C (113 °F) 130 °C (266 °F)
Thick PTFE*** Steel -10 °C (14 °F) 60 °C (140 °F) -10 °C (14 °F) 90 °C (194 °F)
45 °C (113 °F) 130 °C (266 °F)
Thick PTFE*** Stainless steel -20 °C (-4 °F) 60 °C (140 °F) -25 °C (-13 °F) 90 °C (194 °F)
Æ40 °C (-40 °F)** 45 °C (113 °F) 130 °C (266 °F)
PFA*** Steel -10 °C (14 °F) 60 °C (140 °F) -10 °C (14 °F) 90 °C (194 °F)
45 °C (113 °F) 130 °C (266 °F)
PFA*** Stainless steel -20 °C (-4 °F) 60 °C (140 °F) -25 °C (-13 °F) 90 °C (194 °F)
Æ40 °C (Æ40 °F) ** 45 °C (113 °F) 130 °C (266 °F)
ETFE*** Steel -10 °C (14 °F) 60 °C (140 °F) -10 °C (14 °F) 90 °C (194 °F)
45 °C (113 °F) 130 °C (266 °F)
ETFE*** Stainless steel -20 °C (-4 °F) 60 °C (140 °F) -25 °C (-13 °F) 90 °C (194 °F)
Æ40 °C (Æ40 °F)** 45 °C (113 °F) 130 °C (266 °F)
Linatex* Steel -10 °C (14 °F) 60 °C (140 °F) -10 °C (14 °F) 70 °C (158 °F)
Linatex* Stainless steel -20 °C (-4 °F) 60 °C (140 °F) -20 °C (-4 °F) 70 °C (158 °F)
Ceramic carbide Steel -10 °C (14 °F) 60 °C (140 °F) -10 °C (14 °F) 80 °C (176 °F)
Ceramic carbide Stainless steel -20 °C (-4 °F) 60 °C (140 °F) -20 °C (-4 °F) 80 °C (176 °F)
* Only for China production site
** For (optional) low-temperature version only
*** Only for design level ‘A’
