88 FEP630, FEH630 ELECTROMAGNETIC FLOWMETER | CI/FEP630/FEH630-EN REV. D

… 12 Appendix

… Torque information

Nominal diameter [mm (in)] Pressure rating Hard / soft rubber PTFE

** [Nm] *** [Nm] ** [Nm] *** [Nm]

DN 200 (8 in) PN10 —

—

123.6 123.6

PN16 —

—

113 116.9

PN25 —

—

70.42 73

PN40 —

—

109.9 112.5

CL150 —

—

208.6 136.8

CL300 —

—

158.1 158.1

DN 250 (10 in) PN10 —

—

86.06 89.17

PN16 —

—

99.42 103.1

PN25 —

—

166.5 133.9

PN40 —

—

279.9 241

CL150 —

—

146.1 148.3

CL300 —

—

246.4 246.4

DN 300 (12 in) PN10 —

—

91.29 94.65

PN16 —

—

113.9 114.8

PN25 —

—

151.1 106.9

PN40 —

—

254.6 252.7

CL150 —

—

203.5 198

CL300 —

—

421.7 259.1

DN 350 (14 in) PN10 —

—

72.49 75.22

PN16 —

—

124.9 104.4

PN25 —

—

226.9 167.9

CL150 —

—

270.5 263

CL300 —

—

463.9 259.4

DN 400 (16 in) PN10 —

—

120.1 113.9

PN16 —

—

191.4 153.8

PN25 —

—

404 246.7

CL150 —

—

229.3 222.8

CL300 —

—

635.8 328.1

DN 450 (18 in) CL150 —

—

267.3 192.3

CL300 —

—

660.9 300

DN 500 (20 in) PN10 —

—

153.9 103.5

PN16 —

—

312.1 224.8

PN25 —

—

477.1 286

CL150 —

—

237.3 230.4

CL300 —

—

786.8 363.1

DN 600 (24 in) PN10 —

—

238.7 149.1

PN16 —

—

496.7 365.3

PN25 —

—

750.7 539.2

CL150 —

—

451.6 305.8

CL300 —

—

1376 587.4

** Flange material: steel.

*** Flange material: stainless steel.
