23Characteristics
EN
PVS-175-TL
Output
AC Connection to the grid Three phase 3W+PE (TN system)
Nominal AC Output Power (Pacr @cosφ=1) 175 000 W @ 40 °C
Maximum AC Output Power (Pacmax @cosφ=1) 185 000 W @ 30 °C
Maximum apparent Output power (Smax) 185 000 VA
Rated AC Output Voltage (Vacr) 800 V
Output voltage range (Vacmin...Vacmin) 552...960 V (3)
Maximum output current (Iacmax) 134 A
Contribution to short-circuit current 140 A
Rated Output Frequency (fr) 50 Hz / 60 Hz
Output Frequency Range (fmin...fmax) 45...55 Hz / 55…65 Hz (3)
Nominal power factor and setting interval
> 0.995, 0...1 inductive/capacitive with
maximum Smax
Total harmonic distortion of current <3%
Maximum AC Cable outer diameter / multi core 1 x 53 mm (1 x M63 cable gland)
Maximum AC Cable outer diameter / single core 3 x 32 mm (3 x M40 cable gland)
AC Connections Type
Busbar for lug connections with M10 bolts
(included);
Single core cable gland plate with 4 individual
AC cable glands: 3 x M40: Ø 22...32mm, 1 x M32:
Ø 18...25mm
Multi core cable gland plate (optional) with 2
individual AC cable glands: 1 x M63: Ø
37…53mm, 1x M32 Ø 18...25mm)
Output protection
Anti-islanding Protection According to local standard
Maximum external AC overcurrent protection 200 A
Output overvoltage protection - Varistor (-S / -S2 models) Yes
Output overvoltage protection -
Modular surge arresters (-SX / -SX2 models)
Type 2
Operating performance
Maximum Efficiency (ηmax) 98.7%
Weighted Efficiency (EURO) 98.4%
Communication
Embedded communication interfaces
1x RS485, 2x Ethernet (RJ45), WLAN
(IEEE802.11 b/g/n @ 2,4 GHz)
User Interface 4 LEDs, Web User Interface, Mobile APP
Communication protocol Modbus RTU/TCP (Sunspec compliant)
Commissioning tool Web User Interface, Mobile APP
Remote monitoring services Aurora Vision® monitoring portal
Advanced features
Embedded logging, direct telemetry data
transferring to ABB cloud
Environmental
Ambient temperature range
-25...+60°C /-13...140°F with derating above
40°C / 104 °F
Storage temperature -40°C...+85°C / -40°F...185°F
Relative Humidity 4…100 % with condensation
Typical noise emission pressure 65 dB(A) @ 1 m
Maximum operating altitude without derating 2000 m / 6560 ft
Environmental pollution degree
classification for external environments
3
Environmental class Outdoor
Climatic category according to IEC 60721-3-4 4K4H
