24 Product manual - PVS-175-TL;A.1 Version
EN
PVS-175-TL
Physical
Environmental Protection Rating IP 65 (IP54 for the cooling section)
Cooling System Forced air
Dimensions (H x W x D)
867x1086x419 mm / 34.2”x42.7”x16.5” for -S,
-SX model
867x1086x458 mm / 34.2”x42.7”x18.0” for -S2,
SX2 model
Weight
~76 kg / 167,5 lbs for power module ;
~77 kg / 169,7 lbs for Wiring box
Overall max ~153 kg / 337,2 lbs
Assembly System Mounting bracket support
Overvoltage rating as per IEC 62109-1 II (DC input) III (AC output)
Safety
Safety class I
Insulation Level Transformerless
Marking CE
Safety, EMC and Radio Spectrum Standards
IEC/EN 62109-1, IEC/EN 62109-2,
EN 61000-6-2, EN 61000-6-4, EN 61000-3-11,
EN 61000-3-12, EN 301 489-1, EN 301 489-17,
EN 300 328, EN 62311
Grid standard
(check the availability with your sales channel)
CEI 0-16, UTE C 15 712-1, JORDAN IRR-DCC-MV,
BDEW, P.O. 12.3, DRRG D.4
Accessories
Assembly accessories
PVS-175 Installation Kit
AC multicore cable gland plate
(Supports M63 Ø 37…53mm + M32 Ø
18...25mm)
DC Series Arc Fault Circuit Interrupter
Type I acc. to UL 1699B(4) with single-MPPT
sensing capability
DC link recharge circuit Night time operation with restart capability
Anti-PID(5) Based on night time polarization of the array
1. In the event of a fault, limited by the external protection envisaged on the AC circuit
2. According to standard IEC60947.3 Table D.5
3. The AC voltage and frequency range may vary depending on specific country grid standard
4. Performance in line with the relevant requirements of the Draft IEC 63027 standard
5. Cannot operate simultaneously when installed in conjunction with the DC link recharge circuit
6.
Hereby, Power-One Italy S.p.A. (A Member of the ABB Group) declares that the radio equipments (radio
module combined with the inverter), to which this user manual refers, are in compliance with the
Directive 2014/53/EU. The full text of the EU Declaration of Conformity is available at the following
internet address: www.abb.com/solarinverters.
NOTE – D Features not specifically mentioned in this data sheet are not included in the product.
NOTE – D The technical data provided in this manual does not substitute the data supplied on
the labels affixed to the equipment.
